| Pallet depth minimum | 870 |
| Pallet depth maximum (mm) | 1150 |
| Pallet width minimum (mm) | 1200 |
| Pallet width maximum (mm) | 1520 |
| Minimum manufacturing height (mm) | 25 |
| Maximum manufacturing height (mm) | 500 |
| Table vibration Variotronic, 1 table, pallet dept max. 1150 mm | Option |
| Table vibration Variofrequency, 1 table, pallet dept max. 1150 mm | Standard |
| Standard hydraulics, Bosch-Rexroth | Standard |
| MAC 8 control with 2 tamper head cylinders | Option |
| Tamper head clamping, pneumatic | Standard |
| Tamper head clamping, hydraulic (non Hess machine moulds) | Option |
| Tamper head cross cleaner, straight | Option |
| Mold clamping, pneumatic | Standard |
| Hydraulic function for mold flaps | Option |
| Electrical mold extension with pusher (for machines without face mix) | Option |
| Mold change, manual | Option |
| Mold change, electrical | Standard |
| Mold change crane | Option |
| Hydraulic fast lift feeder (fast mold change) | Option |
| Horizontal adjustment table plate, electric | Option |
| Vertical adjustment table plate, electric | Standard |
| Coarse mix part, movable, including pneumatic clamping | Option |
| Coarse mix silo 2 flapps | Option |
| Coarse mix Colormix drawplate | Option |
| Coarse mix silo, silo lining PA/Hardox | Option |
| Coarse mix filler box pneum. Scraper | Option |
| Agitator with cylinder drive | Standard |
| Face mix, electrically movable, including pneumatic clamping | Standard |
| Face mix Colormix drawplate | Option |
| Face mix silo, silo lining PA/Hardox | Option |
| Face mix filler box planing roller | Option |
| Face mix filler box pneum. Scraper | Option |
| Face mix filler box rotating brush | Option |
| Drawplate device build in pallet transport | Option |
| Drawplate device hydraulic / core pulling device | Option |
| Core pulling device, separately | Option |
| Styrofoam inserter, swiveling | Option |
| Cooling tower for hydraulics | Option |
| Emergency mode hydraulics function | Option |
